Fast Track Guide 3. Configuring the Mediant 1000
Version 5.0 19 October 2006
5. Map outgoing calls to IP addresses (when Gatekeeper isn’t used) by completing these steps:
a. Click the arrow button next to the ‘Tel to IP Routing Table’ label; the ‘Tel to IP Routing’
screen opens. Any telephone number whose destination number matches the prefix
defined in the ‘Destination Phone Prefix’ field
and whose source number matches the
prefix defined in the adjacent ‘Source Phone Prefix‘ field is sent to the IP address
entered in the ‘IP Address’ field.
b. Click the Submit button; the ‘Tel to IP Routing’ table is automatically updated.
c. Click Quick Setup; the ‘Quick Setup’ screen opens.
For more information on the ‘Tel to IP Routing’ table refer to the Mediant 1000 H.323 User’s
Manual.
6. Enable E1/T1 B-channels (applicable only for Mediant 1000 digital interfaces) by performing
the following:
a. Click the arrow button next to the ‘Trunk Group Table’ label; the ‘Trunk Group Table’
screen opens.
b. From the ‘Trunk ID’ drop-down list, select the trunk number that you want to enable.
c. In the ‘Channels’ field, enter the number of B-channels that you want to enable.
d. In the adjacent ‘Phone Number’ field, enter the starting phone number (these are virtual
numbers used only to define enabled B-channels).
e. Click the Submit button; the ‘Trunk Group Table’ table is automatically updated.
f. Click Quick Setup; the ‘Quick Setup’ screen opens.
7. Click the Reset button, and then at the prompt, click OK; the Mediant 1000 applies the
changes and restarts.
8. After the gateway is reset, configure the Mediant 1000 analog ports (refer to Section 3.5 on
page 22) and / or Mediant 1000 trunk parameters (refer to Section
3.6 on page 25).
Note: For H.323 users, continue with Section 3.5 on page 22.
