Installation Manual 36 Document #: LTRT-59809
MediaPack Series
Tip:
Once the device is configured, backup your settings by saving the
configuration (ini) file to your PC. This saved file can later be used, if
necessary, to restore configuration settings (refer to 'Backing Up and
Restoring Configuration' on page 39).
¾ To configure basic SIP parameters, take these 6 steps:
1. Access the Web interface.
2. Select the voice coders used by the device that best suits your VoIP network in the
'Coders Table' page (Configuration tab > Protocol Configuration menu > Protocol
Definition submenu > Coders).
3. When operating with a Proxy server, perform the following in the 'Proxy & Registration'
page (Configuration tab > Protocol Configuration menu > Protocol Definition
submenu > Proxy & Registration); otherwise, skip to Step 4:
a. Set the ‘Use Default Proxy’ field to ‘Yes’.
b. (Optional) In the ‘Proxy Name’ field, enter the Proxy's name. The Proxy name
replaces the Proxy IP address in all SIP messages. This means that messages
are still sent to the physical Proxy IP address, but the SIP URI contains the Proxy
name instead.
c. Configure ‘Enable Registration’ to either one of the following:
♦ ‘Disable’ = the device doesn't register to a Proxy/Registrar server (default).
♦ ‘Enable’ = the device registers to a Proxy/Registrar server at power up and
every user-defined interval (‘Registration Time’ parameter).
d. Click the Proxy Set Table button. Enter the IP address of the Proxy server(s).
When no Proxy is used, the internal routing table is used to route the calls.
4. Enable the device's endpoints in the 'Endpoint Phone Number Table' page
(Configuration tab > Protocol Configuration menu > Endpoint Number submenu >
Endpoint Phone Number).
5. If a Proxy server is not implemented, map outgoing calls to IP addresses in the ‘Tel to
IP Routing’ page (Configuration tab > Protocol Configuration menu > Routing
Tables submenu > Tel to IP Routing). For a brief description, refer to 'Configuring
Ports' on page 36.
Save your settings to
the flash memory and reset the device (refer to 'Saving and
Resetting the Device' on page 38).
