8. When successfully completed, a notification window will appear.
In order to be able to use the bit Nove again, you must close
the program on the PC and turn the bit Nove off.
Disconnect the Power supply connector on the bit Nove.
9. Set the "UPGRADE" switch to the OFF position.
Connect the Power supply connector on bit Nove.
10. Turn the bit Nove back on and restart the PC software.
If the bit Nove firmware update was completed
correctly, the dialogue window will show:
- new bit Nove Firmware version.
11. Repeat the product calibration operations
(see sec. 7.2).
8
