Audison Bit Nove - Connection Panel Description; Logo Status

5
USER’S MANUAL
bit Nove /
4. CONNECTION PANELS - DESCRIPTION
LOGO STATUS
The logo led light indicates the processor status:
- BLUE Logo On: bit Nove is switched on.
- Flashing BLUE Logo: product mode set to Upgrade Mode ON, or product being updated
(see section 4.11).
1
7 6
81
10
11
12
2 3 4 59
4
