AUMA EQ 150 - Actuator Features and Functions

Features and functions of actuator
YesSelf-locking
90° ±15°Standard:Swing angle (option)
120° ±15°
150° ±15°
180° ±15°
Options:
[SWE]
HandwheelManual operation
Mechanical end stops, adjustable from outsideEnd positions
Internal terminal rail, for terminal assignment refer to terminal planStandard:Electrical connection
●
Separate electrical terminal compartment at actuator with 32-pole terminal rail [ASK]
●
Compact connector 10-pole silver/24-pole silver [KS1, KS3]
Options:
3 blanking plugs M20 x 1.5Cable entry
Polycarbonate (flammability class V0)Standard:Hood
Aluminium with indicator glassOptions:
●
MANUAL/AUTO change-over
●
Rotary switch (non latching) for OPEN and CLOSE [VSE]
Local controls [VSE] (option), IP65
With base and lever (option)
●
With lever size 100 mm (distance from axis to bore) [LAG-HEB]
●
Lever lengths 150/200 mm on request
Lever size
Features and functions of actuator controls
2 switches for limit seating in the end positions. Used to set the limit positions for the end
positions.
Standard:Limit switching and digital outputs
●
Additional limit switches for signalling the end positions or intermediate positions,
freely adjustable max. 250 V AC, max. 10 A (resistive load), max. 5 A (inductive load),
max. 2 switches [2WE]
●
Additional limit switches for signalling the end positions or intermediate positions,
freely adjustable with gold-plated contacts for low voltage, max. 30 V AC, max. 0.1 A
(resistive load), max. 2 switches [2WE-G]
Options:
2 switches used to switch off the actuator when reaching the maximum torque. Not ad-
justable
Standard:Torque switching and digital outputs
2 additional potential-free torque switches [2DE] signalling once the maximum torque is
reached, not adjustable. Max. 250 V AC, max. 10 A (resistive load), max. 5 A (inductive
load)
Option:
NoneStandard:Digital inputs
With 2 inputs (reversing contactors) for OPEN and CLOSE, option for:
●
24 V DC; 1,7 W appropriate for PLC [WSE]
●
24 V AC/DC
●
110 V AC
●
230 V AC
Options:
Positioning electronics for actuator control [PEL100, PEL-GL]
Input 0 – 10 V, 0/4 – 20 mA, output 0 – 10 V, 0/4 – 20 mA
Positioner (option)
●
Potentiometer 100/130/200/500/1 000/5 000 Ωor 10 kΩ [POT]
Linearity fault ≦0.5 %, max. 1.5 W, wiper current 30 mA, max. 2 units
●
Electronic position feedback signal 2/3-wire technology [ESR100]
Output 0/4 – 20 mA, connecting voltage 24 V DC
Position feedback signal, analogue
(options)
Emergency operation module (option)
●
250 Nm, supply voltage 24 V DC [PSC20-24]
●
250 Nm, supply voltage 90 – 264 V AC [PSC20-230]
●
450 Nm, supply voltage 90 – 264 V AC [PSC40-230]
Emergency operation module
