Information: Please state device type and our order number (see name plate) when ordering spare parts. Only
original AUMA spare parts should be used. Failure to use original spare parts voids the warranty and exempts
AUMA from any liability. Delivered spare parts may slightly vary from the representation in these instructions.
TypeDesignationRef.
no.
TypeDesignationRef.
no.
Sub-assemblyScrew plug539.0Sub-assemblyHousing001.0
Handwheel with ball handle542.0Sub-assemblyDrive shaft005.0
Sub-assemblyMechanical position indicator553.0Sub-assemblyMotor coupling005.1
Sub-assemblySocket carrier for motor plug/socket
connector with cable harness
554.0Manual drive coupling005.3
Sub-assemblyPotentiometer for position transmitter556.0Sub-assemblyWorm wheel006.0
Sub-assemblyPotentiometer without slip clutch556.1Sub-assemblyPlanetary gearing for manual drive009.0
Sub-assemblyHeater557.0Torque lever017.0
Sub-assemblyBlinker transmitter including pins at
wires (without impulse disc and insula-
tion plate)
558.0Sub-assemblyGear segment018.0
Sub-assemblyControl unit with torque switching
heads and switches
559.0Crown wheel019.0
Sub-assemblyControl unit with magnetic limit and
torque transmitter (MWG) for Non-in-
trusive version in combination with
AUMATIC integral controls
559.0Sub-assemblyDrive pinion II for torque switching022.0
Sub-assemblySwitch stack for direction OPEN560.0–1Sub-assemblyOutput drive wheel for limit switching023.0
Sub-assemblySwitch stack for direction CLOSE560.0–2Sub-assemblyDrive wheel for limit switching024.0
Sub-assemblySwitch for limit/torque560.1Sub-assemblyLocking plate025.0
Switch case560.2Sub-assemblyWire for protective earth058.0
Sub-assemblyPosition transmitter EWG/RWG566.0Sub-assemblyMotor (VD motor incl. ref. no. 079.0)070.0
Sub-assemblyPotentiometer for RWG without slip
clutch
566.1Sub-assemblyPlanetary gearing for motor drive
(SQ/SQR 05.2 – SQ SQR 14.2 for VD
motor)
079.0
Sub-assemblyPosition transmitter board for RWG566.2Sub-assemblyReduction gearing155.0
Sub-assemblyWire harness for RWG566.3Sub-assemblyCover500.0
Sub-assemblySlip clutch for potentiometer567.1Sub-assemblySocket carrier (complete with sockets)501.0
Sub-assemblyMotor coupling on motor shaft583.0Sub-assemblyPin carrier without pins502.0
Sub-assemblyPin for motor coupling583.1Sub-assemblySocket for control503.0
Retaining spring for motor coupling584.0Socket for motor504.0
Sub-assemblyOutput drive flange with end stop596.0Sub-assemblyPin for controls505.0
Sub-assemblyScrew plug for end stop612.0Sub-assemblyPin for motor506.0
SetSeal kit, smallS1Sub-assemblyCover for electrical connection507.0
SetSeal kit, largeS2Sub-assemblyCoupling525.0
42
SQ 05.2 – SQ 14.2/SQR 05.2 – SQR 14.2
Spare parts
