12. Technical data
Information The following technical data includes standard and optional features. For detailed
information on the customer-specific version, refer to the order-relevant data sheet.
This data sheet can be downloaded from the Internet at http://www.auma.com in
German and English (indication of commission number required).
12.1 Features and functions of actuator
Standard:
SA: Short-time duty S2 - 15 min
SAR: Intermittent duty S4 - 25 %
Options:
SA: Short-time duty S2 - 30 min
SAR: Intermittent duty S4 - 50 %
SAR: Intermittent duty S5 25 %
Type of duty
1)
Refer to actuator name plateTorque range
Refer to actuator name plateOutput speed
Standard: 3-ph AC asynchronous motor, type IM B9 according to IEC 60034Motor
Standard: F, tropicalized
Option: H, tropicalized
Insulation class
Standard: Thermoswitches (NC)
Option: PTC thermistors (according to DIN 44082)
2)
Motor protection
Self-locking:
-
SA/SAR 25.1 30.1: Output speeds up to 90 rpm (50 Hz), 108 rpm (60 Hz)
-
SA 35.1 SA 48.1: Output speeds up to 22 rpm (50 Hz), 26 rpm (60 Hz)
NOT self-locking:
-
SA 35.1 SA 48.1: Output speeds from 32 rpm (50 Hz), 38 rpm (60 Hz)
Multi-turn actuators are self-locking, if the valve position cannot be changed from standstill
while torque acts upon the output drive.
Self-locking
Counter gear mechanism for end positions CLOSED and OPEN
Turns per stroke: 1 to 500 (standard) or 1 to 5,000 (option)
Standard:
Single switches (1 NC and 1 NO; not galvanically isolated) for each end position
Options:
Tandem switches (2 NC and 2 NO) for each end position, switches galvanically isolated
Triple switches (3 NC and 3 NO) for each end position, switches galvanically isolated
Intermediate position switch (DUO limit switching), adjustable for any position
Limit switching
Torque switching adjustable for directions OPEN and CLOSE
Standard:
Single switches (1 NC and 1 NO; not galvanically isolated) for each direction
Option:
Tandem switches (2 NC and 2 NO) for each direction, switches galvanically isolated
Torque switching
Potentiometer or 0/4 20 mA (RWG)Position feedback signal, ana-
logue (option)
Continuous indication, adjustable indicator disc with symbols OPEN and CLOSEDMechanical position indicator
(option)
Blinker transmitter (standard for SA, option for SAR)Running indication
Self-regulating PTC heater, 5 20 W, 110 250 V AC/DC
Option: 24 48 V AC/DC or 380 400 V AC
Heater in switch compartment
110 120 V AC/DC: 50 W
220 240 V AC/DC: 50 W
380 400 V AC/DC: 22 W
Motor heater (option)
Manual drive for setting and emergency operation, handwheel does not rotate during electrical
operation.
Option: Handwheel lockable
Manual operation
36
SA 25.1 SA 48.1/SAR 25.1 SAR 30.1
Technical data
