Up to100 % relative humidity across the total permissible temperature rangeHumidity
Within actuator controls: pollution degree 2
Outside actuator controls (in closed condition): pollution degree 4
Pollution degree
Standard: Two-component iron-mica coatingFinish coating
Standard: AUMA silver-grey (similar to RAL 7037)Colour
Refer to name plate
Standard:
●
–40 °C to +40 °C
Options:
●
–50 °C to +40 °C
●
–60 °C to +60 °C
Low temperature versions incl. heating system for connection to external power supply 230
V AC or 115 V AC.
Ambient temperature
Open-close duty (operating cycles OPEN - CLOSE - OPEN):
SG 05.1 – SG 07.1: 20,000
SG 10.1: SG 15,000
SG 12.1: 10, 000
Lifetime
Refer to separate technical dataWeight
12.5 Accessories
AUMATIC mounted separately from the actuator, including plug/socket connector. Connecting
cables on request. Recommended for high ambient temperatures, difficult access, or in case
of heavy vibration during service
Wall bracket
1)
AUMA ToolSuiteProgramming software for PC
Cable length between actuator and AUMATIC max. 100 m. Not suitable for version with potentiometer in the actuator. Instead of the
potentiometer, an RWG has to be used.
1)
12.6 Further information
●
ATEX Directive: (94/9/EC)
●
Electromagnetic Compatibility (EMC): (2004/108/EC)
●
Low Voltage Directive: (2006/95/EC)
●
Machinery Directive: (2006/42/EC)
EU Directives
75
SGExC 05.1 – SGExC 12.1 Control unit: electromechanic
ACExC 01.2 Intrusive Modbus RTU Technical data
