AUMA SGExC 05.1 User Manual

Information: Please state type and commission no. of the device (see name plate) when ordering spare parts.
Only original AUMA spare parts should be used. Failure to use original spare parts voids the warranty and exempts
AUMA from any liability. Delivered spare parts may slightly vary from the representation.
TypeDesignationNo.
Sub-assemblyHousing001.0
Sub-assemblyWorm shaft002.0
End stop nut (included in sub-assembly 002.0)002.4
Sub-assemblyManual drive worm003.0
Sub-assemblyWorm wheel004.0
Sub-assemblyMounting flange005.0
Sub-assemblyEnd stop010.0
Protective cap016.1
Sub-assemblyTorque finger017.0
Sub-assemblyLimit drive finger021.0
Sub-assemblyManual drive bearing029.0
Sub-assemblyPlanetary gearing032.0
Sub-assemblyMotor034.0
Sub-assemblyMotor electronic board034.3
Sub-assemblyVaristor board034.4
Sub-assemblySocket carrier with motor cable harness041.0
Sub-assemblyTorque switching head061.0
Sub-assemblyCover500.0
Sub-assemblySocket carrier (complete with sockets)501.0
Screw for control terminal501.1
Washer for control terminal501.2
Screw for power terminal501.3
Washer for power terminal501.4
Sub-assemblyPin carrier without pins502.0
Sub-assemblyPin for controls505.0
Sub-assemblyPin for motor506.0
Sub-assemblyPlug cover507.0
Coupling525.0
Sub-assemblyHandwheel542.0
Sub-assemblyBall handle542.1
Sub-assemblyMechanical position indicator553.0
Sub-assemblyPotentiometer for position transmitter556.0
Potentiometer without slip clutch556.1
Sub-assemblyHeater557.0
Sub-assemblyBlinker transmitter including pins at wires (without impulse disc and insulation plate)558.0
Sub-assemblyControl unit without torque switching heads and switches559.0-1
Sub-assemblyControl unit with magnetic limit and torque transmitter (MWG) for Non-intrusive version in combination
with AUMATIC integral controls
559.0-2
Sub-assemblySwitch stack for direction OPEN560.0-1
Sub-assemblySwitch stack for direction CLOSE560.0-2
Switch for limit/torque switching560.1
Switch case560.2
Sub-assemblyPosition transmitter RWG566.0
Sub-assemblyPotentiometer for RWG without slip clutch566.1
Sub-assemblyElectronic board RWG566.2
Sub-assemblyWire harness for RWG566.3
Sub-assemblySlip clutch for potentiometer567.1
SetSeal kit, smallS1
SetSeal kit, largeS2
77
SGExC 05.1 – SGExC 12.1 Control unit: electromechanic
ACExC 01.2 Intrusive Modbus RTU Spare parts
