AUMA SGExC 05.1 User Manual

Information: Please state type and commission no. of the device (see name plate) when ordering spare parts.
Only original AUMA spare parts should be used. Failure to use original spare parts voids the warranty and exempts
AUMA from any liability. Delivered spare parts may slightly vary from the representation in these instructions.
TypeDesignationNo.
Sub-assemblyLocal controls002.0
Sub-assemblyLocal controls board002.3
Sub-assemblyFace plate for display002.4
Sub-assemblyPower supply unit006.0
Sub-assemblyI/O board008.1-1
Sub-assemblyFieldbus board008.1-2
Sub-assemblyLogic board009.0
Sub-assemblyRelay board011.1
Sub-assemblyOption board012.1
Sub-assemblyCover500.0
Sub-assemblyTerminal board501.0
Screw for control terminal501.1
Washer for control terminal501.2
Screw for power terminal501.3
Washer for power terminal501.4
Sub-assemblyPin carrier (without pins)502.0
Sub-assemblyPin for controls505.0
Sub-assemblyPin for motor506.0
Sub-assemblyPlug cover507.0
Sub-assemblySwitchgear508.0
Padlock509.1
Sub-assemblyFuse kit510.0
Sub-assemblyCable conduit (actuator connection)532.0
Circlip535.1
SetSeal kitS
79
SGExC 05.1 – SGExC 12.1 Control unit: electromechanic
ACExC 01.2 Intrusive Modbus RTU Spare parts
