Table 29:
DescriptionSignal
Input not assigned
Not used
Change-over between OPEN - CLOSE control and setpoint control
MODE
Operation command OPEN
OPEN
Operation command CLOSE
CLOSE
Operation command STOP
STOP
Reset fault signal
RESET
Change-over between fieldbus interface and parallel interface
I/O interface
Operation command OPEN/CLOSE for two-wire control
OPEN / CLOSE
Operation mode for EMERGENCY behaviour
EMERGENCY
Operation command: Run to intermediate position 1.
Intermediate pos. 1
Operation command: Run to intermediate position 2.
Intermediate pos. 2
Operation command: Run to intermediate position 3.
Intermediate pos. 3
Operation command: Run to intermediate position 4.
Intermediate pos. 4
Operation command: Run to intermediate position 5.
Intermediate pos. 5
Operation command: Run to intermediate position 6.
Intermediate pos. 6
Operation command: Run to intermediate position 7.
Intermediate pos. 7
Operation command: Run to intermediate position 8.
Intermediate pos. 8
Operation command: Run to intermediate position 9.
Intermediate pos. 9
Operation command: Run to intermediate position 10.
Intermediate pos. 10
Operation command: Run to intermediate position 11.
Intermediate pos. 11
Operation command: Run to intermediate position 12.
Intermediate pos. 12
Operation command: Run to intermediate position 13.
Intermediate pos. 13
Operation command: Run to intermediate position 14.
Intermediate pos. 14
Operation command: Run to intermediate position 15.
Intermediate pos. 15
Operation command: Run to intermediate position 16.
Intermediate pos. 16
Clockwise approach of position 1
MPV: CW Position 1
Counterclockwise approach of position 1
MPV: CCW Position 1
Clockwise approach of position 2
MPV: CW Position 2
Counterclockwise approach of position 2
MPV: CCW Position 2
Clockwise approach of position 3
MPV: CW Position 3
Counterclockwise approach of position 3
MPV: CCW Position 3
Clockwise approach of position 4
MPV: CW Position 4
Counterclockwise approach of position 4
MPV: CCW Position 4
Approach position 5 clockwise
MPV: CW Position 5
Approach position 5 counterclockwise
MPV: CCW Position 5
Approach position 6 clockwise
MPV: CW Position 6
Approach position 6 counterclockwise
MPV: CCW Position 6
Approach position 7 clockwise
MPV: CW Position 7
Approach position 7 counterclockwise
MPV: CCW Position 7
Approach position 8 clockwise
MPV: CW Position 8
Approach position 8 counterclockwise
MPV: CCW Position 8
Approach position 9 clockwise
MPV: CW Position 9
Approach position 9 counterclockwise
MPV: CCW Position 9
Approach position 10 clockwise
MPV: CW Position 10
Approach position 10 counterclockwise
MPV: CCW Position 10
Approach position 11 clockwise
MPV: CW Position 11
Approach position 11 counterclockwise
MPV: CCW Position 11
155
Actuator controls
ACV 01.2/ACVExC 01.2 Profibus DP Appendix
