DescriptionSignal
Approach position 12 clockwise
MPV: CW Position 12
Approach position 12 counterclockwise
MPV: CCW Position 12
Approach position 13 clockwise
MPV: CW Position 13
Approach position 13 counterclockwise
MPV: CCW Position 13
Approach position 14 clockwise
MPV: CW Position 14
Approach position 14 counterclockwise
MPV: CCW Position 14
Approach position 15 clockwise
MPV: CW Position 15
Approach position 15 counterclockwise
MPV: CCW Position 15
Approach position 16 clockwise
MPV: CW Position 16
Approach position 16 counterclockwise
MPV: CCW Position 16
Clockwise actuator operation
MPV DriveCW
Counterclockwise actuator operation
MPV DriveCCW
Signal for controlling output contact
Input DIN 1
Signal for controlling output contact
Input DIN 2
Signal for controlling output contact
Input DIN 3
Signal for controlling output contact
Input DIN 4
Enables the selector switch function (LOCAL/OFF) on the local controls
Enable Local
Interlock: Enables operation command in direction OPEN
Enable OPEN
Interlock: Enables operation command in direction CLOSE
Enable CLOSE
Internal PID setpoint
PID internal setpoint 2
Activation of operation mode Remote II
Remote2_active
Operation command OPEN in operation mode Remote II
Remote2_OPEN
Operation command CLOSE in operation mode Remote II
Remote_2_CLOSE
Operation command STOP in operation mode Remote II
Remote2_STOP
PVST is executed
Execute PVST
Enable signal for <By-pass function>
Bypass Sync In
Change-over of process controller setpoint source between fieldbus interface and I/O interface
PID setpoint I/O
Change-over of process controller actual value source between fieldbus interface and I/O interface
PID act. value I/O
Enable signal OPEN/CLOSE
RelOPENandCLOSE
Signal 1 for external speed selection
Speed int. sel. bit 0
Signal 2 for external speed selection
Speed int. sel. bit 1
156
Actuator controls
Appendix ACV 01.2/ACVExC 01.2 Profibus DP
