Configuration of digital input
Required user level: Specialist (4).
Device configuration M0053
I/O interface M0139
Digital inputs M0116
Example
Use input DIN4 for signal EMERGENCY:
Parameters: Signal DIN 4 M0118
Setting value: EMERGENCY
Information
The logic for the digital inputs may be inverted. Depending on the parameter setting
(e.g. Coding DIN 4M0126), the input is either High active or Low active. For safety
reasons, the EMERGENCY signal input is generally set to Low active.
Execute EMERGENCY operation via digital input
Switching behaviour for coding Low active:
●
EMERGENCY = low level (0 V DC or input open)
EMERGENCY operation is initiated.
●
EMERGENCY = high level (default: +24 V DC):
No EMERGENCY operation
13.2.1. Activate EMERGENCY behaviour
Required user level: Specialist (4) or higher.
Device configuration M0053
Application functions M0178
Activation M0212
EMCY behaviour M0589
Default value: Function not active
Setting values:
Function not active
<EMERGENCY behaviour> function deactivated.
Function active
<EMERGENCY behaviour> function activated.
For activated EMERGENCY behaviour:
Risk of actuator operation due to an EMERGENCY signal!
Risk of personal injuries or damage to the valve.
→
Ensure that the EMERGENCY input is not activated when switching on. This
means connect the EMERGENCY signal appropriately.
→
Actuators with Combi-Switch: If the actuator starts unexpectedly, immediately
turn selector switch to position OFF.
→
Actuators with magnetic pen control panel: If the actuator starts unexpectedly,
immediately tap OFF with the magnetic pen.
→
If the actuators starts unexpectedly and parameter EMCY operation mode equals
Remote, Local and Off: immediately disconnect from mains.
Information
EMERGENCY behaviour must be completely configured during first activation.This
means the setting of the following parameters in particular must be adapted to the
required actuator behaviour: Failure/EMCY tripping Source EMCY operation mode
EMCY operation Failure/EMCY position
13.2.2. Emergency tripping
Required user level: Specialist (4) or higher.
Customer settings M0041
76
Multi-turn actuators
Failure functions TR-M30X – TR-M1000X
