Setting value: Execute PVST
Information
The logic for the digital inputs may be inverted. Depending on the parameter setting
(e.g. Coding DIN 4M0126), the input is either High active or Low active. For safety
reasons, the Execute PVST signal input is generally set to Low active.
Execute PVST via digital input
Switching behaviour for coding Low active:
●
Execute PVST input = low level (0 V DC or input open)
No test
●
Execute PVST input = high level (default: +24 V DC)
Test is initiated
Execute PVST manually via local controls
Required user level: Specialist (4) or higher.
Device configuration M0053
Service functions M0222
Execute PVST M0850
The actuator must be in the initial position.The initial position depends on the following
parameter settings: PVST behaviour M0853, PVST stroke M0854
Information
PVST can be aborted by sending a Reset command:
●
in operation mode LOCAL , via ESC (Escape).
●
in operation mode REMOTE / via a digital input. Assignment: RESET
●
Actuators with fieldbus or communication interface: via fieldbus, Reset
command, byte 1 bit 3 of output data (in operation mode REMOTE
/ ).
13.7. Bluetooth interface can be activated and deactivated (security)
The Bluetooth interface behaviour can be set.
Device configuration M0053
Application functions M0178
Activation M0212
Bluetooth M0573
The parameter Bluetooth may have the following values:
0
Switched off (CDT & App)
Off (local controls)
1
Switched on (CDT & App)
On (local controls)
2
I/O or fieldbus
3
Selector switch position OFF (CDT & App)
Selector switch OFF (local controls)
The Bluetooth interface is permanently switched off for parameter value “0”. It is
impossible to establish a connection.
The Bluetooth interface is permanently switched on and ready for reception for
parameter value “1”. A connection can be established at any time.
The parameter values “2” and “3” will be explained hereafter.
Activation/deactivation via I/O, fieldbus or selector switch position OFF
The Bluetooth interface can have three different states:
BT_OFF
The Bluetooth interface is switched off.To establish a connection via a master is not
possible.The Bluetooth LED (blue) of the local controls is switched off.
85
Multi-turn actuators
TR-M30X – TR-M1000X Failure functions
