14.7. Monitoring power supply of electronics
Integral controls monitor the following voltages and signal a warning (refer to <Fault
signals and warnings> chapter):
●
Auxiliary voltage 24 V DC, e.g for supplying the control inputs
●
Voltage 24 V AC for controlling the reversing contactors, for thermoswitches
and heater within the actuator and for generating the 115 V AC auxiliary voltage
for the customer (option)
●
Internal 24 V DC power supply of the electronics components (within the integral
controls and in the actuator)
●
External 24 V DC supply of the electronics (option)
Activate monitoring of auxiliary voltage 24 V DC
Required user level: Specialist (4).
Device configuration M0053
Monitoring function M0645
Monitor 24 V DC cust. M0650
Default value: Function not active
Setting values:
Function not active
Monitoring is deactivated.
On
Monitoring is activated. Should the auxiliary voltage 24 V DC for supplying the control
inputs fail, a warning will be issued.
Activate the monitoring of the external 24 V DC supply
Required user level: Specialist (4).
Device configuration M0053
Monitoring function M0645
Monitor 24 V DC ext. M0649
Default value: Function not active
Setting values:
Function not active
Monitoring is deactivated.
On
Monitoring is activated. Should the external supply 24 V DC fail, a warning will be
issued.
14.8. Temperature monitoring
Properties
If the respective sensors are installed in the devices, the integral controls monitor
different temperatures.
If certain temperature limits are exceeded or fallen short of, the controls either send
a warning or a fault signal.
Requirements
●
for motor temperature: additional temperature sensor (PT 100) in the motor
●
for gear housing temperature: additional temperature sensor (PT 100) in the
gearing
Information
Current device temperatures can also be displayed. Refer to <Display device tem-
peratures>.
14.9. Monitoring the heating system/heater
The heating system within the housing can be monitored. If the monitoring is activated,
the following warning will be generated if the heater system fails:
●
Status indication in the display of the local controls S0005 Warnings
-
Details: Internal warning Wrn heater
●
Via fieldbus: Wrn heater
97
Multi-turn actuators
TR-M30X – TR-M1000X Monitoring functions
