When changing the parameter value, the Bluetooth interface behaviour pattern in
“BT_READY” and “BT_OFF” states is as follows:
Table 10: Change of parameter value
New statusNew parameter valueCurrent statusCurrent parameter
value
BT_READY1 (switched on)BT_OFF0 (switched off)
BT_OFF2 (fieldbus or I/O)BT_OFF0 (switched off)
BT_OFF3 (selector switch posi-
tion OFF)
BT_OFF0 (switched off)
BT_OFF0 (switched off)BT_READY1 (switched on)
BT_OFF2 (fieldbus or I/O)BT_READY1 (switched on)
BT_OFF3 (selector switch posi-
tion OFF)
BT_READY1 (switched on)
BT_OFF0 (switched off)BT_READY or BT_OFF2 (fieldbus or I/O)
BT_READY1 (switched on)BT_READY or BT_OFF2 (fieldbus or I/O)
BT_OFF3 (selector switch posi-
tion OFF)
BT_READY or BT_OFF2 (fieldbus or I/O)
BT_OFF0 (switched off)BT_READY or BT_OFF3 (selector switch posi-
tion OFF)
BT_READY1 (switched on)BT_READY or BT_OFF3 (selector switch posi-
tion OFF)
BT_OFF2 (fieldbus or I/O)BT_READY or BT_OFF3 (selector switch posi-
tion OFF)
If the Bluetooth interface is in “BT_CONNECTED” state, a change of parameter value
does not cause a status change. In order to change the status, the master must
interrupt the connection or the connection must be interrupted otherwise:
Table 11: Status change for disconnect or abort
New statusCauseCurrent statusCurrent parameter
value
BT_OFFDisconnect by masterBT_CONNECTED0 (switched off)
BT_OFFAbort by DCSBT_CONNECTED0 (switched off)
BT_READYDisconnect by masterBT_CONNECTED1 (switched on)
BT_CONNECTEDAbort by DCSBT_CONNECTED1 (switched on)
BT_READY (until
timeout)
Disconnect by masterBT_CONNECTED2 (fieldbus or I/O)
BT_OFFAbort by DCSBT_CONNECTED2 (fieldbus or I/O)
BT_READY (until
timeout)
Disconnect by masterBT_CONNECTED3 (selector switch posi-
tion OFF)
BT_OFFAbort by DCSBT_CONNECTED3 (selector switch posi-
tion OFF)
Timeout for Bluetooth activation
The time the Bluetooth interface remains in “BT_READY” state after activation via
“selector switch position OFF” or after connection abort by the Bluetooth master, can
be set via parameter .
Device configuration M0053
Bluetooth interface M2235
Timeout BT active M2234
Default value: 180 [s]
Setting range: [60 ... 300] [s]
87
Multi-turn actuators
TR-M30X – TR-M1000X Failure functions
