Check that the wiring is completed for:
Please use the screws provided.
Ensure the orientation arrow is
pointing upwards.
You are ready to secure the rear housing to the wall box.
Power Terminals
Sensor Terminals (if applicable)
Installation - Thermostat Mounting
(JGSTATW2)
1
2
INSTALLATION
