Aura JGSTATW2W - Installation - System Parameters

You are now ready to configure the unit using the
system parameter table below.
*Grouping requires a wiring centre. Please refer to page 6. Additionally you must
have a PRT for grouping to operate. Two groups are the maximum allowed per
wiring centre.
** This setting is used when there is only a system receiver only in the system. If
there is a system receiver set to RX1 used along with wiring centre, radiator valves
and system receiver set to RX2 then RX1 will communicate automatically to the
thermostat connected to these other devices.
31
www.speedfitUFH.co.uk
Installation - System Parameters
SX FUNCTION SYSTEM DEFINITION DEFAULT
SETTING
System Unit
0 Programmable Stat (PRT)
S01
Type
1 Digital Thermostat 0
2 HW Timer
What does unit 0* Aura Wiring Centre*
S02
Communicate 1 Aura radiator valve 0
with in the Aura 2 System Receiver set for RX2
system 3** System Receiver set to RX1**
INSTALLATION
