JGSTATW Instruction Manual
Installation - Technical Detail
Model JGSTATW1 / JGSTATW2
Type Wireless Electronic programmable room thermostat (PRT),
digital room thermostat and Hot Water Timer
Programming Modes User selectable for 5/2, ALL and Individual day options
Program Number 1 - 6 Selectable
Modes Party, Holiday, Program and Frost
Override Permanent and temporary
Frost Protection 5ºC Adjustable
Power Source 230v AC 50Hz JGSTATW2 - 4 x AAA JGSTATW1
Temperature Scale 5ºC to 35ºC, tolerance 0.5ºC
Heat/Cool Global changeover using communication bus and external
input to the wiring centre
Sensor Air or floor protection. Cylinder thermostat when configured
for hot water timer.
Device Parameters See pages 58 - 59 for full list of functions
Operating Temperature 0 to 50ºC
Storage Temperature -20 to 60ºC
Frequency 2.4HGz Zigbee
