DX FUNCTION SYSTEM DEFINITION DEFAULT
SETTING
D08 Frost Set point 5ºC - 17ºC Required Temperature for frost 5ºC
Temperature protection and holiday mode
D09 Hour Format 0 12
1
1 24
D10 N/A N/A N/A N/A
D11 Daylight Saving 0 OFF
1
Time (DST) 1 ON
D12 Heating Set point
5ºC - 35ºC
Maximum temp that can
35ºC
Limit be set for heating
D13 Cooling Set point
5ºC - 40ºC
Maximum temp that can
5ºC
Limit be set for Cooling
D14 Floor sensor High Output relay will be switched off
Limit Temperature 6ºC -45ºC when temp is reached for 27ºC
floor protection
D15 Floor sensor Low Output relay will be switched on
Limit Temperature 6ºC - 45ºC when temp is reached for 10ºC
floor protection
D16 Floor sensor Limit Output relay will be switched off
for cooling 6ºC -45ºC when temp is reached for 6ºC
floor protection
59
www.speedfitUFH.co.uk
Installation - Device Parameters continued
INSTALLATION
