Aurora PVI-AEC-EVO - Page 93

PVI-AEC-IRR
3 - APPENDIX
+Vcc
-Vcc /
AIn_RTN
PVI-AEC-T1000-INTEGR
AIn 1
(temperature)
1
12
3
4
5
6
2
Wiring Diagrams for the Sensor PVI-AEC-T1000-INTEGR
>ANALOG INPUT1
t1000-integr
*
Display Settings:
PVI-AEC-EVO / PVI-AEC-EVO LIGHT
QUICK INSTALLATION GUIDE
