D 900 AP / D 1000 AP / D 1000 APG
21
(fi g. 1)(fi g. 2)
Controls
instruments
equipment
Multifunction switch (fig. 1, 2)
Located on the steering column.
Direction indicators. Moving the lever (a) from its neutral position towards the driver,
the left direction indicator is selected and pushing the lever forwards, the right direction
indicator is selected. When the direction indicators are selected, the lamp (l) (see fig.3
of the previous page) blinks on the control panel.
Position / low beam / road lights and dazzle lights. By turning the lever (a) to the first
position the position lights are turned on. By turning it to the second position the low
beam lights are turned on. By pushing the lever down the high beam is turned on. Pulling
the lever upwards selects the dazzle lights.
Horn. Activated by pressing the end of the multifunction switch.
Use of accessories and equipment
In the case of the vehicle being equipped with accessories, before using them, carefully
read the specific instructions manual for the accessory provided by its manufacturer and
supplied together with the main dumper manual.
In the case of accessories and equipment being assembled on the basic chassis of
the dumper by companies not connected to the manufacturer, all prescriptions and
limitations of the dumper in relation to mass and dimensions, efficiency of the lighting
system and adjustments thereto, along with the need for protection for additional
systems must be taken into account in order to guarantee the safety of the dumper.
a
