AUSA D 900 AP - Engine Oil and Cooling System Maintenance

D 900 AP / D 1000 AP / D 1000 APG
41
(fi g. 3) (fi g. 2) (fi g. 1)
3.- Engine oil
 Engine oil level (fig. 1, 2, 3)
CAUTION:
Frequently check the level and refill if necessary. Do not exceed the maximum level.
Operating the engine with an inappropriate oil level could severely damage the engine.
Clean any spills.
With the vehicle on a level surface and the engine stopped and cold, check the oil level
in the following way.
a. Dipstick
- Pull the oil level dipstick (a), remove it from its housing and clean it with a clean
cloth (fig. 1).
- Place the dipstick in its housing.
- Remove it once again from the housing and check the oil level. It must be up to
or equal to the upper level marked (fig. 2).
b. Full
c. Add
d. Operating range
- Add oil up to the upper level mark if required.
- To add oil, remove the oil level dipstick. Place a funnel in the oil filling hole located
to the right side of the engine.
e. Filling hole (fig. 3)
Do not exceed the maximum level.
- Properly cover the oil filling hole and correctly store the oil level dipstick.
Periodic
maintenance
operations
a
e
