D 900 AP / D 1000 AP / D 1000 APG
65
Electric diagram
Name Description Pag.
A11 Alternator 1
B7 Engine oil minimum pressure switch 1
B10 Coolant temperature warning switch 1
B13 Horn 3
B23 Air filter blockage indicator 1
B28 Brake lights pressure switch 4
E2 Working light 3
E29 Right headlight 4
E30 Left headlight 4
E31 Rear left light 4
E32 Number plate light 4
E33 Rear right light 4
E69 Rotating beacon 3
F1 (+30) warning fuse (7,5A) 1
F2 Reverse speed buzzer/left position light fuse (5A) 2
F3 Position light fuse (5A) 2
F4 Low beam fuse (10A) 4
F5 High beam fuse (10A) 4
F6 (+15) joystick fuse (7,5A) 2
F7 (+15) front and reverse solenoids + horn fuse (10A) 2
F8 (+15) starter/stop engine solenoid fuse (10A) 1
F9 (+15) warning lights fuse (7,5A) 1
F10 (+15) rotating beacon fuse (15A) 3
F11 (+15) optional fuse 10A 2
FG1 (+30) permanent live maxfuse (50A) 1
FG2 (+50) starter motor relay maxfuse (40A) 1
FG3 (+15) pre-heater relay maxfuse (50A) 1
FG4 Optional maxfuse 1
G399 Battery 1
H12 Dashboard buzzer 2
H15 Reverse relay 2
HF Parking brake sensor 2
K1 Permision start relay 1
K2 Forward relay 2
K3 Reverse relay 2
K4 Reverse alarm relay 2
Name Description Pag.
K5 Parking brake relay 2
K5 Horn relay 4
K6 Dashboard buzzer relay 2
K6 Low beam light relay 4
K7 High beam light relay 4
K8 Flasher relay 4
K18 Starter motor relay 1
K19 Pre-heating relay 1
L1 Air filter blockage warning light 1
L2 Engine oil pressure warning light 1
L3 Pre-heating warning light 1
L4 Battery charge warning light 2
L5 Coolant temperature switch warning light 1
L6 Low fuel level warning light 1
L7 Position lights warning light 4
L8 High beam warning light 4
L9 Flasher warning light 4
M9 Starter motor 1
M99 Fuel pump 1
R6 Engine pre-heating resistance 1
S1 Joystick 2
S36 Starting switch 1
S38 Horn switch 3
S39 Rotating beacon switch 3
S40 Warning switch 4
S41 Working light switch 3
S43 Steering column light switch 4
S44 Hour meter 1
S60 Disable rear gear buzzer switch (op.1) 2
S299 Shift gear push button 2
SA? Solder number ? 1/2
X?? Connector number ?? 1/2/3
Y1 Forward electrovalve 2
Y2 Reverse electrovalve 2
Y8 Engine stop solenoid 1
