D. Charging Handle Safety Lock — Press to release charging
handle from its cradle
E. Charging Handle, Type 2
F. Cradle
G. EV Charge Cable
NOTE
Drape the EV charge cable over the top of the
MaxiCharger and dock the connector in its
holster when not in use. See the figure on the
left.
The maximum length of the EV charge cable is
7.5 meters.
