General Characteristics
IP and IK Rating
 Cable model: IP65, IK08
 Socket/shutter model: IP54,
IK08
Operating Altitude 2,000 m
Humidity < 95 % RH, non-condensing
Operating Temperature
Range
-40 °C to + 55 °C
Storage Temperature
Range
-40 °C to + 85 °C
Mounting Wall or floor using a pedestal
Dimensions
(H × W × D)
 Cable: 336 x 187 x 85 mm
 Socket/shutter: 336 × 187 × 115
mm
Weight
 Cable (5 m) model: 7.4 kW/11
kW: 4.7 kg ; 22 kW: 6.2 kg
 Cable (5 m) + LCD model: 6.45 kg
 Socket model: 7.4 kW: 3.3 kg ;
22 kW: 3.4 kg
 Socket + LCD model: 4.2 kg
 Shutter model: 7.4 kW: 3 kg ; 22
kW: 3.1 kg
