mode, and one Help button on the right for access to additional
information.
Each parameter item displays the selected mode independently.
1) Analog Gauge Mode – displays the parameters in the form of an
analog meter graph.
2) Text Mode – this is the default mode which displays the parameters
text, displaying in list format.
NOTE
Status parameters, such as a switch reading, can primarily be viewed in text
form such as ON, OFF, ACTIVE, and ABORT. Whereas, value parameter,
such as a sensor reading, can be displayed in text mode and additional
graph modes.
3) Waveform Graph Mode – displays the parameters in waveform
graphs.
When this mode is selected, three control buttons display on the right
side of the parameter item for manipulation of display status.
Text Button – resumes Text Display Mode.
Scale Button – changes the scale values that are displayed below
the waveform graph. There are four scales available: x1, x2, x4
and x8.
Zoom-in Button – tap to display the selected data graph in full
screen.
Edit Button – tap this button to open an edit window, on which
you can set the waveform color and the line thickness
displayed for the selected parameter item.
Scale Button - changes the scale values, which are displayed
below the waveform graph. There are four scales available: x1,
x2, x4 and x8.
Zoom-out Button – exits full screen display.
4) Digital Gauge Mode – displays the parameters in form of a digital
gauge graph.
Full Screen Display – this option is only available in the waveform
graph mode, and primarily in Graph Merge status for data comparison.
