SECTION 3 − DEFINITIONS
3-1. Additional Safety Symbols And Definitions
. Some symbols are found only on CE products.
Warning! Watch Out! There are possible hazards as shown by the symbols.
Safe1 2012−05
3-2. Miscellaneous Symbols And Definitions
. Some symbols are found only on CE products.
A
Amperage
V
Voltage
Positive
Negative
Direct Current
(DC)
Alternating
Current (AC)
Single Phase
Hz
Hertz
Input
Input Voltage
Output
Single Phase
Transformer
Rectifier
Off
On
Work Connection
Flux Cored Arc
Welding (FCAW)
FCAW Gun With
Switch
Do Not Switch
While Welding
Wire Feed
Circuit Breaker
Increase
Percent
Protective Earth
(Ground)
Temperature
Line Connection
s
Suitable For
Welding In An
Environment With
Increased Risk Of
Electric Shock
X
Duty Cycle
I
1
Rated Supply
Current
I
2
Rated Welding
Current
I
1eff
Maximum
Effective Supply
Current
I
1max
Rated Maximum
Supply Current
U
0
Rated No−Load
Voltage (OCV)
U
1
Rated Supply
Voltage
U
2
Conventional
Load Voltage
IP
Internal Protection
Rating
