OM-270 231 Page 33
SECTION 10 − PARTS LIST
10-1. Parts List
Description
Part
No.
Dia.
Mkgs.
Auto Arc Toolmate 100
Quantity
Item
No.
1 270620 Door, Access (Includes) 1... .......... .. ..............................................
270659 Label, Welding Guide 1................ .... ..............................................
2 270621 Wrapper, Cover (Includes) 1... .......... .. ...........................................
270609 Label, Warning General Precautionary 1................ .... ...............................
3 270622 Hinge, Door Access 2... .......... .. .................................................
4 CB1 270623 Supplementary Protector, Man Reset 1P 25A 250VAC FR 1... ... .. .. ................
5 SR1 270624 Rectifier Assembly, 1PH 125 A 500V PIV 25% Duty Cycle 1... ... .. .. ................
6 S1 270625 Switch, Rocker DPST 16A 250VAC On-None-Off .250 CC 1... .... .. .. ................
7 R1 270626 Pot, CP Plat 1T 0.2W 5K Linear 1... .... .. .. ......................................
8 S2 270627 Switch, Rotary 5 Posn 1... .... .. .. ...............................................
9 PC1 270628 Circuit Card Assy, Control 1... ... .. .. ............................................
10 270631 Kit, Spool Hub Replacement 1... .......... .. ..........................................
11 270632 Bezel, Front/Rear (Black) 1... .......... .. ............................................
12 270633 Knob, Pointer 1.188 Dia 2... .......... .. .............................................
13 FM 270634 Fan, Muffin 115V 50/60Hz 2200 RPM 4.135 Mtg Holes 1... ... .. .. ...................
14 PL1 270682 Light, Ind Amber Lens 125V Snap-In Mtg .500 Mtg Hol 1... ... .. .. ...................
15 270629 H100F2-8 Gun. 030-.035 1... .......... .. ............................................
16 DM1 270630 Drive Assy, Wire 1... ... . .. ....................................................
17 240594 Label, Warning, Electric Shock And Pinch 1... .......... .. ..............................
To maintain the factory original performance of your equipment, use only Manufacturer’s Suggested
Replacement Parts. Model and serial number required when ordering parts from your local distributor.
10-2. Accessories
Part No. Description Remarks
194 776 Small Running Gear/Cylinder Rack For One Small Gas Cylinder, 75 lb (34 kg)
270 629 H100F2-8 Gun .030−.035 8 ft (2.4 m) length/.030-.035 (0.8-0.9 mm) Wire Size
10-3. Consumables
Item Hobart Package Part No.
Contact Tip .030 in. (0.8 mm) 770 177 (5 per package)
Contact Tip .035 in. (0.9 mm) 770 180 (5 per package)
Gasless Flux Cored Nozzle 770 487
Tip Adapter 770 402
Replacement Liner .030/.035 in. (0.8/0.9 mm) 210 970R
Replacement Drive Roll .023/.025 in. (0.6 mm) and .030/.035 in (0.8/0.9 mm) V and VK Groove 212 379R
SECTION 11 − WARRANTY
LIMITED WARRANTY – Subject to the terms and conditions below. Hobart Brothers Co., Troy, Ohio, warrants to its original
retail purchaser that the new Auto Arc equipment sold after the effective date of this limited warranty is free of defects in material
and workmanship at the time it is purchased at the retailer. THIS WARRANTY IS EXPRESSLY IN LIEU OF ALL OTHER WAR-
RANTIES, EXPRESS OR IMPLIED, INCLUDING THE WARRANTIES OR MERCHANTABILITY AND FITNESS.
Auto Arc equipment is warranted for twelve months from the date of purchase. Proof of purchase is required for warranty
transactions so it is imperative that a copy of the original invoice or sales receipt be retained.
For warranty transactions, contact your original Auto Arc retailer or call 1−800−332−3281
Effective January 1, 2015AutArc 12Mon 2015-01
