90
Used in control program
Properties
Units
Default
1
2
3
4
5
6
7
8
9
10
11
12
Miscellaneous
No Heating Above*** Deg 110 X X X X X
X X X X X X
100% Heating Below*** Deg 100 X X X X X
X X X X X X
100% Cooling Above*** Deg 48 X X X X X
X X X X X X
No Cooling Below*** Deg 40 X X X X X
X X X X X X
Min OA Damper Pos % 20
X X
X
Activate Rev Valve For
Heat Cool Heat Cool
Turn fan on when TLO is
pressed?
Yes
X X
X X
Configure Heating display
text****
AO or BO X X X X X X X X X X X X
Configure Cooling display
text****
AO or BO X X X X X
X X X X X X
Temp Sensor Calibration
Offset
Deg 0 X X X X X X X X X X X X
*
**
***
****
The minimum time the PID output will take to increase from 0100% or to decrease from 100–0%.
Within the PID deadband, the integral value remains fixed and the loop operates on proportional
control only.
The heating or cooling output is limited by this discharge temperature limit.
Does not affect control operation. Only determines which type of output triggers display of the Heating or
Cooling text.
