Diamond PD Power Drive : Instruction Manual
Dominator EasyRoller Instruction Manual
7
© Copyright 2018
4.3 Unsuitable Door Types
The drive must not be used with a door incorporating a wicket door, unless
the drive cannot be operated with the wicket door open. The fitting of an
opener to doors with removable mullions is not recommended.
4.4 Sideroom
The minimum sideroom required from the edge of the door curtain is 1
9
/
16
”
to the inside of the door bracket, and 3
3
/
8
” to the wall. If a Battery Backup is
to be fitted, at least 5
5
/
16
” to the bracket is required.
Therefore the recommended sideroom from the edge of the door curtain
is 5
5
/
16
” to the inside of the door bracket, and 6
7
/
8
” to the wall as per
Fig 4.4.1.
4. Setup Requirements
4.2 The Opener:
a. MUST BE installed in a dry position, protected from weather. (Moisture or corrosion not covered by Warranty)
b. Is factory set for RIGHT HAND SIDE installation (from inside garage), but capable of LEFT HAND SIDE installation. Fig 4.2.1
c. REQUIRES properly earthed 3 pin single phase power within an arms length of door and at a suitable height
d. Requires a MINIMUM SIDEROOM of 1
9
/
16
” from the edge of the door to the inside of the door bracket and 3
3
/
8
” to the wall.
e. CAN NOT be installed on a Door Axle Diameter that exceeds 1
3
/
8
”.
Fig. 4.2.1
Fig. 4.4.1
WARNING! This operator is not equipped for permanent wiring.
Contact a qualified electrician to install a suitable receptacle if
one is not available.
AVERTISSEMENT! Ce dispositif d’ouverture n’est pas conçu
pour un câblage permanent. En l’absence de réceptacle
approprié, contactez un électricien qualifié pour en installer un.
CAUTION: Do not connect opener to power source
until instructed to do so.
ATTENTION: Ne branchez pas l’ouvre-porte avant d’y
être autorisé par la notice.
6
7
/
8
”
5
5
/
16
”
Minimum Side room Recommended Side room
1
9
/
16
”
3
3
/
8
”
LEFT HAND SIDE RIGHT HAND SIDE
3
3
/
8
”
1
9
/
16
”
3
3
/
8
”
1
9
/
16
”
To Next Page
