3. Specifications
Technical Specifications
Power supply 230V - 240Va.c. 50Hz
Maximum door opening:
Width:
Height:
Weight:
5500mm (16.5m
2
)
3000mm
100kg
Minimum headroom 25mm
Short Term Peak Force 800N (80kg)
Rated force 500N (50kg) with Chain
450N (45kg) with Timing Belt
Nominal force 150N (15kg)
Receiver type UHF Multi-frequency FM Receiver
Receiver code storage capacity 64 X 4 button Transmitter Codes
Transmitter frequency TrioCode
TM
Type
Coding type Mulit-frequency Code Hopping
Number of code combinations Over 4.29 billion random codes
Code generation Non-linear encryption algorithm
Transmitter battery CR2032 (3 Volts)
Courtesy light Bright LED
Note: Intermittent operations may occur in areas which experience very strong winds. The strong wind
puts extra pressure on the door and tracks which may in turn intermittently trigger the safety obstruction
detection system.
