7.4 Test the Battery Back Up (Optional
Accessory)
a. Press the transmitter to activate.
b. Whilst the door is in motion disconnect mains
power - the opener should continue to operate.
c. Press the transmitter to activate the door.
d. Whilst the door is in motion re-connect
power. The door should complete the cycle
as normal.
7. Safety Testing
7.1 Test the Close Cycle
a. Press the transmitter to open the door. (Fig 7.1)
b. Place a piece of timber approximately 40mm high on
the floor directly under the door (Fig 7.2).
c. Press the programmed transmitter to close door.
d. The door should strike the object and re-open.
7.2 Testing the Open Cycle
a. Press the transmitter to close the door (Fig. 7.1).
b. Press again to open the door.
c. When the door reaches approximately half way,
firmly grab the door’s bottom rail - the door should
stop.
If the door does not reverse readily when closing, or
stop when opening, put the door into manual and
contact your installer immediately for a door service.
CAUTION: Take care when
completing a safety test. Failure
to follow this warning can result
in serious personal injury and/or
property damage.
40mm
WARNING! If the door is closing
and is unable to re-open when
obstructed, discontinue use.
Do not use a door with faulty
obstruction sensing. Contact
your dealer for support.
Fig. 7.2
7.3 Test the Manual Door Operation
Periodically disengage the opener (Section 6.1)
and manually operate the door. The door must be
smooth to operate by hand. The force required on
the bottom rail should not exceed 15 kg.
Select the button on
the transmitter that has
been programmed to
operate the door.
If transmitter is not programmed,
Refer to Section 8 to program
transmitter.
Fig. 7.1
NOTE: Wait for the door to complete its travel
before proceeding to the next step.
