Chapter 4: AC Drive Parameters
GS1 Series AC Drive User Manual
4–4
Digital (cont.)
GS1
Parameter
Description Range Default
3-11
Multi-Function Output Terminal
0: AC Drive Running
1: AC Drive Fault
2: At Speed
3: Zero Speed
4: Above Desired Frequency (3-16)
5: Below Desired Frequency (3-16)
6: At Maximum Speed
7: Over torque detected
8: Above Desired Current (3-17)
9: Below Desired Current (3-17)
0
3-16
Desired Frequency 0.0 to 400Hz 0.0
3-17
Desired Current 0.0 to Drive Rated Amps 0.0
Analog
4-00
Source of Frequency Command
0: Frequency determined by keypad
potentiometer
1: Frequency determined by digital keypad
up/down
2: Frequency determined by 0 to +10V
input on AI terminal with switch
3: Frequency determined by 4 to 20mA
input on AI terminal with switch
4: Frequency determined by 0 to 20mA
input on AI terminal with switch
5: Frequency determined by RS-485
communication interface
0
4-01
Analog Input Offset Polarity
0: No Offset
1: Positive Offset
2: Negative Offset
0
4-02
Analog Input Offset 0.0 to 100.0% 0.0
4-03
Analog Input Gain 0.0 to 300.0% 100.0
4-04
Analog Input Reverse
Motion Enable
0: Forward Motion Only
1: Reverse Motion Enable
0
4-05
Loss of ACI Signal (4-20mA)
0: Decelerate to 0Hz
1: Stop immediately and display error
code “EF”
2: Continue operation by the last frequency
command
0
Presets
5-00
Jog 0.0 to 400Hz 6.0
5-01
Multi-Speed 1 0.0 to 400Hz 0.0
5-02
Multi-Speed 2 0.0 to 400Hz 0.0
5-03
Multi-Speed 3 0.0 to 400Hz 0.0
Parameter can be set during RUN Mode.
