Chapter 4: AC Drive Parameters
GS1 Series AC Drive User Manual
4–6
Protection (cont.)
GS1
Parameter
Description Range Default
6-31
Present Fault Record
0: No Fault occurred
1: Over-current (oc)
2: Over-voltage (ov)
3: Overheat (oH)
4: Overload (oL)
5: Overload 1 (oL1)
6: Overload 2 (oL2)
7: External Fault (EF)
8: CPU failure 1 (CF1)
9: CPU failure 2 (CF2)
10: CPU failure 3 (CF3)
11: Hardware Protection Failure (HPF)
12: Over-current during accel (OCA)
13: Over-current during decel (OCd)
14: Over-current during steady state (OCn)
18: External Base-Block (bb)
19: Auto Adjust accel/decel failure (cFA)
20: Software protection code (codE)
0
6-32
Second Most Recent Fault Record 0
6-33
Third Most Recent Fault Record 0
6-34
Fourth Most Recent Fault Record 0
6-35
Fifth Most Recent Fault Record 0
6-36
Sixth Most Recent Fault Record 0
Display
8-00
User Defined Display Function
0: Output Frequency (Hz)
1: Motor Speed (RPM)
2: Output Freq. X 8-01
3: Output Current (A)
4: Motor Output Current (%)
5: Output Voltage (V)
6: DC Bus Voltage (V)
9: Frequency Setpoint
0
8-01
Frequency Scale Factor 0.1 to 160.0 1.0
Parameter can be set during RUN Mode.
To Next Page
