Autronica AutroFlame X33AF - Page 12

Instructions, AutroFlame X33AF, 116-P-X33AF/IGB, rev. E, 2013-08-13, P/N 95-8625-17.1, Rev: 2/13
Autronica Fire and Security AS
Page 8
Figure 4—X33AF Terminal Block
9
8
7
6
5
4
3
2
1
19
18
17
16
15
14
13
12
11
4-20 mA +
4-20 mA –
4-20 mA + REF
4-20 mA – REF
COM FIRE
COM FIRE
N.O. FIRE
N.O. FIRE
N.C. FIRE
N.C. FIRE
COM FAULT
COM FAULT
N.O. FAULT
N.O. FAULT
24 VDC +
24 VDC +
24 VDC –
24 VDC –
24 VDC –
29
28
27
26
25
24
23
22
21
SPARE
SPARE
COM AUX
N.O. AUX
N.C. AUX
RS-485 A
RS-485 B
MAN O
i
C2061
Figure 5—X33AF Wiring Terminal Identication
3/8 INCH (10 MM) GAP MINIMUM
1112
13
141516171819
B2126
BULKHEAD
Figure 6—EOL Resistor Installation (For Ex d Wiring only)
