9.5 How to Operate in Menu Mode
All menu selections represent a digit. To enter a menu selection, you
simply have to press the corresponding digit. Then you can either;
• use the keyboard to enter text into an input field
or
• press the ENTER button ( ) and use the up/down arrows to move
the cursor to the desired selection.
9.6 Example - How to Disable Detection Zones
• From the top level of the Menu, press, for example, digit 2 to select
DISABLE
MENU
19:23
Total: 3
1 SHOW STATUS
2 DISABLE
3 ENABLE
4 SYSTEM
5 SERVICE
MENU
19:23
Total: 3
1 SHOW STATUS
2 DISABLE
3 ENABLE
4 SYSTEM
5 SERVICE
• Press digit 3 to select DETECTION ZONES.
DISABLE
19:23
Total: 3
1 DETECTION ZONES
2 POINTS
3 FIRE ALARM DEVICES
4 FIRE ALARM ROUTING EQUIPMENT
5 OUTPUTS
6 FAULT WARNING ROUTING EQUIPMENT
7 IMMEDIATE OUTPUT ACTIONING
DISABLE
19:23
Total: 3
1 DETECTION ZONES
2 POINTS
3 FIRE ALARM DEVICES
4 FIRE ALARM ROUTING EQUIPMENT
5 OUTPUTS
6 FAULT WARNING ROUTING EQUIPMENT
7 IMMEDIATE OUTPUT ACTIONING
Figure 9-2: Disable Menu
• Now, you can either;
a) Use the keyboard to enter text into the input field.
or
b) Press the ENTER button ( ), then use the up/down arrows to
move the cursor to the desired selection in the selection field.
• Refer to the two subsequent chapters.
