10.9 Show Status – Activated Outputs
This menu gives detailed information on activated outputs.
The example below describes how to view the current status of
activated outputs.
Step Actions to be taken Display Indication
1
To enter the Main Menu, press
!
MENU
19:23
Total: 3
1 SHOW STATUS
2 DISABLE
3 ENABLE
4 SYSTEM
5 SERVICE
2
To select SHOW STATUS, press 1.
SHOW STATUS
1 FIRE ALARMS
2 FIRE WARNINGS
3 FAULTS
4 DISABLEMENTS
5 DETECTION ZONES IN TEST
6 OIL&GAS INHIBITED POINTS
7 ACTIVATED OUTPUTS
19:23
3
To select ACTIVATED OUTPUTS, press 7.
SHOW STATUS
ACTIVATED OUTPUTS
1 DOOR CONTROL UNITS
2 LOW LOCATION LIGHT UNITS
3 STANDARD CONTROL UNITS
4 OTHER OUTPUTS
5 ALL
19:23
SHOW STATUS
ACTIVATED OUTPUTS
1 DOOR CONTROL UNITS
2 LOW LOCATION LIGHT UNITS
3 STANDARD CONTROL UNITS
4 OTHER OUTPUTS
5 ALL
19:23
The 3 steps above will lead you to Show Status – Acitivated Outputs, where you can continue viewing
the status of the activated outputs (1-5), shown on the following page (step 4).
