Controls and options of the Loader Avant 755i 760i
64
.
Additional counterweights
Additional counterweights can be installed to
increase the stability of loader when handling heavy
loads or attachments.
1.
29 kg individual
weights A35957
Max 3 pcs.
If you insta
ll a
trailer coupling,
only one extra
weight can be
used.
2.
80 kg side weight
kit A36401
One 40 kg weight
to both sides of the
loader.
3.
180 kg side weight
kit A49063
One 90 kg weight
installed to both
sides of the loader.
The side weight kits will not increase the total width
of the loader. See page 64 for installation
instructions of side weights.
After adding or removing
counterweights the load sensor
must be calibrated.
You can add or
remove only one 29 kg
counterweight without calibrating.
See page 123
for more
information.
WARNING
Risk of loss of control of loader -
Too much counterweight can
make
the front of the loader too
light.
If you install too much
counterweights to the loader, th
e
front wheels of the loader will be
easily lifted from the ground. This
will make steering of the loader
difficult. If counterweights are fitted
to handle a certain
attachment,
remove counterweights if driving
without an attachment.
CAUTION
Risk of sudden loss of stability -
Always install any
counterweight firmly.
Counterweight can fall from the
loader on uneven ground or after
hitting a wall or other structur
e.
Tighten all fastening screws. After
installing the 180 kg side weight
kit, remove their
lifting slings from
the weights to prevent their use as
tie down points.
Adding or removing counterweights
When installing or removing counterweights
appropriate lifting equipment must be used.
To install or remove side counterweights (180 kg
kit, A49063):
1. Install a lifting eyelet on the threaded hole on
top of the counterweight. See picture below.
