8
IMPORTANT NOTES
1/4" TS phone plug
(mono, unbalanced)
1. Signal
2. Ground, shielding
Note:
1. Use the audio cable correctly; otherwise, the device may fail to work properly.
2. This unit doesn’t have built-in speaker, please connect the amplifier or headphones to play sounds.
3. The instructions in the manual and the contents on the screen may be dierent from the actual ones because
your device may be using a more advanced version of the system.
BOTTOM PANEL
The UNIT can be played flat on a desktop or placed on the most common snare drum stands. A clamp and stand
made specifically for the UNIT are available to purchase at the website.
Note: When using this UNIT, please keep the unit in stable when playing, otherwise, crosstalk may occur, aecting
the performance.
Three-pole 1/8" mini phone jack
(stereo, unbalanced)
1. Signal (left)
2. Signal (right)
3. Ground, shielding
