Cell Antenna Unit
Issue 6 September 2001
3-39
Figure 3-20. Cable Assembly for Outdoor CAUs
.140”
.343”
.436”
B
A
C
E
D
1. Strip cable as shown.
Be careful not to
2. Crimp contact onto
A
3. Slide ferrule over cable.
B
4. Slide connector body
C
onto cable. Make sure foil layer
goes inside connector and that
5. Dress the braid evenly over
the ridged part of
D
6. Slide ferrule into place
E
damage braid.
center conductor.
the braid goes outside.
connector .
and crimp .
