Definity Installation And Test

Hardware Installation
3-40 Issue 6 September 2001
NOTES: The models identified in the previous table are identical. The stripper is available
from Techni-Tool
®
(1-610-941-2400) as Part #618ST020.
NOTES: The Crimpmaster and Maxi-Crimper tools are identical. Order either tool. The
following items are available from Techni-Tool (1-610-941-2400) per the identified part
numbers:
(a) — 462ST506 (Frame Only)
(b) — 462ST578 (Crimp Die)
(c) — 272ST100 (Frame Only)
(d) — 272AC104 (Crimp Die)
9. Form the drip loop in each cable end. Connect each cable end to the
grounding block as shown in the following figure. The outdoor CAU may be
attached to either side of the connector on the grounding block.
Table 3-6. Coaxial Wire Strippers
Manufacturer Model
Xcelite 3CSK-BRI
Ideal 45-521
Table 3-7. Coaxial Connector Crimp Tools
Manufacturer Model Replacement Die
Ideal Crimpmaster
®
#30-483(a) #30-578(b)
Xcelite Maxi-Crimper #MAC8259(a) #D8259(b)
ErgoCrimp Plus #ECP000 (Crimp Tool
Frame Only)(c)
#D104(d)
