7 — Appendices
Service Instructions RP-A301CE/RP-A351CE/RP-A355CE 7 - 41
7.5.2 RP-A351CE
Part No. Description No. off
A1026 Sharpener assembly 1
C4813 Belt 1
C4817 Belt - D322 L100 1
C5812 Capacitor 14uF 1
C5832 Capacitor 35 uF 1
E1420 Cam 1
G5054 Ring - cam interlock 1
I166309 Circuit board 1
Il990A/Red Handle assembly 1
I2040/Red End grip handle 1
I2095/Red Knob assembly - carriage support 1
I3646 Hall effect switch 2 pole 1
I3670 Push switch 1
I3686 Hall effect switch 1
I3704 On/off pushbutton assembly 1
I3705 On/off pushbutton assembly with lamp 1
L062303 Knife 350mm with remover holes 1
M6602 Grinding stone 2
M6621 De-burr stone 2
M7076 Spring (locking lever) 1
M8459 Motor 1
P1034 Stop pin (pusher) 1
P3381 Grinding stone/spindle assembly 1
P3458 De-burr stone/spindle assembly 1
P5017 Foot 4
R2001 Motor start block 1
R4031 Potentiometer 1
S3815 Index arm 1
T1002 Rubber stop (pusher) 1
T5006/Red Centre plate knob assembly 1
T8027 Knife shaft assembly - bronze gear 1
V7014X Knife screw 4
