7 — Appendices
7 - 42 Service Instructions RP-A301CE/RP-A351CE/RP-A355CE
7.5.3 RP-A355CE
Part No. Description No. off
A1026 Sharpener assembly 1
C4813 Belt - carriage motor 1
C4817 Belt - D420 L100 - auto drive 1
C5812 Capacitor 14uF 1
C5881 Capacitor 4700 mF 50V 1
C8232 Contact circuit board 1
E1420 Cam 1
G5054 Ring - cam interlock 1
Il901A/Red Handle (carriage support) 1
I2040/Red End grip handle 1
I2095/Red Knob assembly - carriage support 1
I3646 Hall effect switch 2 pole 1
I3670 Push switch 1
I3686 Hall effect switch 1
I3704 On/off pushbutton assembly 1
I3705 On/off pushbutton assembly with lamp 1
L062303 Knife 350mm with remover holes 1
M6602 Grinding stone 2
M6621 De-burr stone 2
M8242 Motor 1
P1034 Stop pin (pusher) 1
P3381 Grinding stone/spindle assembly 1
P3458 De-burr stone/spindle assembly 1
P5017 Foot 4
R4031 Potentiometer 1
S3250 Daughter board 1
S3251 Circuit board 1
S3802 Index arm 1
T5004/Red Centre plate knob assembly 1
T8024 Knife shaft assembly 1
V7014X Knife screw 4
