7 — Appendices
7 - 18 Service Instructions RP-A301CE/RP-A351CE/RP-A355CE
7.4.6 Option 92 Programmable portioner
lnstructions for use A351CE
Control Panel Description
Continuous function
Weight function
Slices function
In Automatic Working can be programmed three different functions; in the figures
below the different visualisations are described:
Start / Stop
MANUAL: Start the manual blade working only
AUTOMATIC: Start the automatic working both of the feed carriage and the blade
Stop the manual working
Multi-function button to enter the different programmable functions
Button to load data during the programmation
L1: External voltage signalling led
L2: Manual working signalling led
L3: Automatic working signalling led
