4 — Installation
Service Instructions RP-A301CE/RP-A351CE/RP-A355CE 4 - 3
4.1 RP-A301CE/A351CE
4.1.1 Installation
The slicer must be mounted horizontally on
a stable, robust and antiskid base adequate
to support its weight (see 3.1.2 and 3.1.3).
The suggested height of the working table is
about 800 mm.
It must be checked that the product holder
is not clamped and the product to be cut
can be easily loaded (see 3.1.2 and 3.1.3).
4.1.2 Electrical supply
The machine must be installed in the
proximity of a mains socket.
Check that the power supply voltage
corresponds to that described on the
information label and that it is connected to
an adequate earth.
1. Connect the plug.
2. Check that the blade cover fastener
handle is screwed tight.
3. Check that the blade sharpener is
lowered and the protective cover is
closed.
Manual operation
1. Press pushbutton to start blade.
Automatic operation
1. Press pushbutton to start blade.
2. Press pushbutton to start
carriage.
