Section 7
Appendices
Table of Contents:
page no
Service Instructions RP-A301CE/RP-A351CE/RP-A355CE 7 - 1
7.1 Slicer model coding system 7-3
7.2 Service checklist 7-4
7.3 Common faults/Corrective action 7-5
7.4 Options 7-11
7.4.1 Option 3 Slice counter with pre selector 7-11
7.4.2 Option 8 Digital portioner 7-14
7.4.3 Option 12,22 Vegetable chute 135 mm 180 mm dia. 7-15
7.4.4 Option 78 Carriage with dual grippers 7-16
7.4.5 Option 91 Vegetable arm 7-17
7.4.6 Option 92 Programmable portioner 7-18
7.4.7 Option 93 Carriage with dual fixing grippers (250/300) 7-37
7.4.8 Option 81,100 Product fence 7-38
7.5 Recommended parts 7-39
7.5.1 RP-A301CE 7-39
7.5.2 RP-A351CE 7-40
7.5.3 RP-A355CE 7-41
7.4 Exploded view with part numbers 7-42
7.4.1 RP-A301CE 7-42
7.4.2 RP-A351CE 7-52
7.4.3 RP-A355CE 7-64
7.7 Knife remover assemblies 7-77
7.8 Knife part numbers 7-91
