A-2 Equipment Manual
Supplies
Supply Type: Labels and tags, perforated or continuous
Supply Widths: 0.75 inches (19mm) minimum
4.4 inches (112mm) maximum
Supply Lengths: 0.12 inch (3mm) minimum for non-peel mode
1.0 inch (25.4mm) minimum for peel mode
6.0 inches (152.4mm) maximum for peel mode
10 inches (254mm) recommended for non-peel mode
longer lengths are supported up to 1000 inches (25,400mm)
maximum for 203 dpi; and 450 inches (11,430mm) maximum for
300 dpi. Contact your Avery representative for supply
recommendations.
Thickness: 0.002 inches to 0.010 inches (0.055mm to 0.254mm)
Wind Direction: Inside or Outside wound
Note: For inside wound supply, the maximum label length is 6.0
(152.4mm) inches with a 3-inch (76.2mm) core.
Core Diameter: 1.0 inch (25.4mm) to 1.5 inch (38.1mm), cardboard
Internal Label Roll OD: 5.0 inches (127mm)
External Label Roll OD: 8.0 inches (203mm) – requires optional adapter
Ribbon
Ribbon Length: 300 meters (11,811 inches)
Ribbon OD: 2.7 inches (67mm) maximum
Ribbon Core ID: 1.0 inch (25.4mm)
Ribbon Wind Direction: Ink side out
Optional Cutter
Supply Type: Tags, perforated or continuous
Tag Widths: The maximum width using 10 mil (10 point) tags with the cutter
is 1.5 inches; with thinner tag supply, the maximum cut width is
4.0 inches (101.6mm)
The minimum tag width is 0.75 inches (19mm)
Tag Lengths: The minimum tag length is 1.0 inches (25.4mm).
The maximum tag length is 10.0 (254mm)
Tag Thickness: up to 10 mil (10 point)
Print Speed: The maximum print speed with the cutter is 3.0 ips.
Accessories
131688 USB keyboard
13007604 MicroSD Card
12808745 Extra Ribbon Core
131795 203 dpi replacement printhead
131796 300 dpi replacement printhead
131798 Wi-Fi Radio
126894N External Rewinder – includes a 3.0 inch (76mm) core
