XLR-6, XLR-8 and XLR-12 Installation Instructions 13

3.4.2 XLR-6 Connections

If you are connecting to Avery Weigh-Tronix or equipment that uses RS-232

communications, then you will be connecting to connector B (8 pin male). If you are

using Digi-Star equipment then connect to connector A (8 pin female). Use only

supplied cable assemblies from the manufacturer.

Figure 3.5 XLR-6 Connector Configuration
