Avery Weigh-Tronix XLR Series - Service Parts List

26 XLR-6, XLR-8 and XLR-12 Installation Instructions
6.2 Service Parts List
AWTX Part # AWTX Description
XLR-6 Remote Display
AWT05-508244 Complete Remote Display, XLR-6 LED
AWT25-501915 Digit Board, 8 digit x 2”, XLR-6
AWT20-508551 Enclosure, Rear XLR-6 LED Remote
AWT20-508552 Enclosure, Front XLR-6 LED Remote
AWT20-508553 Lens Assy, Non-Glare XLR-6 (adh. gasket inc.)
AWT20-508554 Gasket, XLR-6 Remote
AWT20-508550 Cover, connector, XLR-6
AWT20-508532 Protective Stainless Steel Shield XLR-6
XLR-8 Scoreboard Remote Display
AWT05-503508 Complete Remote Display, XLR-8 LED
AWT20-504260 Enclosure, Rear XLR-8 LED Remote
AWT20-504261 Enclosure, Front XLR-8 LED Remote
AWT20-504262 Lens Assy, Non-Glare XLR-8 (adh. gasket inc.)
AWT20-504263 Gasket, XLR-8 Remote
AWT20-508548 Cover, connector, XLR-8
AWT20-504832 Protective Stainless Steel Shield XLR-8
AWT20-504269 Display Card, 4 Digit XLR Series
XLR-12 Scoreboard Remote Display
AWT05-503509 Complete Remote Display, XLR-12 LED
AWT20-504264 Enclosure, Rear XLR-12 LED Remote
AWT20-504265 Enclosure, Front XLR-12 LED Remote
AWT20-504266 Lens Assy, Non-Glare XLR-12 (adh. gasket inc.)
AWT20-504267 Gasket, XLR-12 Remote
AWT20-508549 Cover, connector, XLR-12
AWT20-504833 Protective Stainless Steel Shield for XLR-12
AWT20-504269 Display Card, 4 Digit XLR Series
XLR Common Parts
AWT20-504268 Controller Board, XLR Series
AWT25-501916 Wiring Harness, male conn., XLR
AWT25-501917 Wiring Harness, female conn., XLR
AWT15-501088 Remote Transmitter
AWT25-500927 Remote Receiver
